Product Description
The EI813F Ethernet Module acts as a communication bridge between the ABB control system and external Ethernet-based networks, enabling seamless data exchange across devices such as HMIs, engineering stations, field instruments, and supervisory systems. It supports 10/100 Mbps full/half duplex Ethernet communication and is engineered to meet the stringent demands of real-time industrial automation networks.
This module is particularly well-suited for complex applications in industries such as oil & gas, power generation, chemical processing, pulp & paper, and water treatment, where reliability, speed, and data integrity are crucial.
Parameter information
| Parameter | Details |
| Model Number | EI813F |
| Part Number | 3BDH000022R1 |
| Manufacturer | ABB |
| Communication Interface | Ethernet (10/100 Mbps, IEEE 802.3 compliant) |
| Ports | 2 x RJ45 Ethernet ports |
| Duplex Mode | Full/Half duplex (auto-negotiation) |
| Protocol Support | TCP/IP, UDP, FTP, SNMP, IEC 60870-5-104 |
| Compatible System | ABB AC 800M, Control Builder M |
| Power Supply Voltage | 24 V DC (supplied via S800 I/O bus) |
| Power Consumption | Typically < 2.0 W |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Protection Class | IP20 |
| Certifications | CE, RoHS, UL, cUL, ATEX |
Key Features
- Dual Ethernet Ports: Allows daisy-chaining or redundancy configurations.
- Fast Data Transfer: 10/100 Mbps transmission speed with auto-negotiation.
- Protocol Versatility: Supports various industrial Ethernet protocols including TCP/IP, SNMP, and IEC standards.
- Reliable Network Performance: Real-time data exchange with high signal integrity.
- Compact & Modular: Fits seamlessly within ABB S800 I/O modules.
- Low Power Consumption: Energy-efficient, minimizing heat and power draw.
- Diagnostics and Status LEDs: Visual indicators for link, activity, and error states.
