Description: Allen-Bradley 1757-SRM ProcessLogix & ControlLogix System Redundancy Module.
This module enables Controller Redundancy by pairing with another 1756-SRM from another ControlLogix chassis. This module is a Two (2) slot module with integrated Fiber Optic port compatible for 62.5/125 micron multi-mode fiber-optic cable with SC connector.
Full Description: Allen-Bradley 1757-SRM ProcessLogix & ControlLogix System Redundancy Module; Supported Controllers: one 1756-L61, 1756-L62, 1756-L63, 1756-L64 controller; Supported Communication Modules (Maximum Seven modules): 1756-CNB series D or E, 1756-CNBR series D or E, 1756-ENBT, or 1756-EWEB modules
Technical specifications for 1757-SRM
|
Backplane current |
0.160 A at 24V DC |
|
Series |
ControlLogix; ProcessLogix |
|
Weight, approx. |
0.452 kg (14.53 oz) |
|
Module Type |
System Redundancy Module |
|
Connector |
SC Type |
|
Mounting |
ControlLogix chassis |
|
Enclosure type rating |
None (open-style) |
|
Cable Type |
62.5/125-micron multi-mode fiber-optic cable |
|
Power dissipation, max |
11.28 W |
|
Supported Controllers |
Logix 5560 |
|
Thermal dissipation, max |
38.49 BTU/hr |
Technical notes
The Allen-Bradley 1757-SRM ProcessLogix and ControlLogix System Redundancy Module is part of a special machine system designed to guarantee the continuing operation of critical processes by providing redundant platforms in the event of major system failures. In the event of a major failure in the primary PLC, the redundancy system detects the failure and allows the secondary PLC to take control of the machine or process in order to keep it running.
