Product Overview
The FBM205, 0 to 20 mA I/O Interface (Redundant) contains four redundant 0 to 20 mA dc analog input channels and four redundant 0 to 20 mA dc analog output channels. The inputs/outputs are galvanically isolated from other channels and ground. A redundant pair of the modules combine to provide redundancy at the Fieldbus Module (FBM) level, with field I/O wired to one common termination assembly . Each module independently attempts to hold the output(s) at its specified output value(s), and each independently reports its observed value of the inputs. A redundant analog input and redundant analog output block in the control software validates each input and output in conjunction with information to/from the module.
Product Specification
Input/Output Channels：4 analog input channels (0–20 mA DC)
Range：0 to 20.4 mA DC
Accuracy：±0.3% of span (includes tolerance of sense resistor in redundant adapter)
Temperature coefficient：±50 ppm/°C
Input Impedance： 60 Ω nominal (resistor in redundant adapter)
A/D Conversion：Each channel performs its own conversion
Integration Period： Software configurable
Common Mode Rejection： >100 dB at 50/60 Hz
Normal Mode Rejection： >95 dB at 50/60 Hz
Product Features
◈Four redundant 20 mA DC analog input channels
◈Four redundant 20 mA DC analog output channels
◈Each input and output channel is galvanically isolated
◈Rugged design suitable for enclosures in Class G3 (harsh) environments
◈Execution of analog input application programs with:
◈High accuracy achieved via sigma-delta data conversions for each channel
◈Termination Assemblies (TAs) for local or remote field wiring connections to the FBM205
◈Redundant loop power for FBM-powered transmitters
◈3-tier termination assembly for per-channel internal and/or external wiring
