The/Invensys/Foxboro FPS400-24 I/A Series DIN Rail Mounted Power Supplies provide 24 V dc to DIN rail mounted baseplates. It is a 400 W power supply that is agency certified for use in Division 2 and Zone 2 applications. There are 2 input voltage power supplies offered: 120/240 V ac or 125 V dc input (P0922YU) and 24 V dc input (P0922YC). These are the only power supplies that have been tested and qualified by for use with 200 Series FBMs.
Product Specifications
Model: Foxboro P0922YU FPS400-24
Output Voltage: 24V DC
Nominal Output Current: 16.7 A
Nominal Output Power: 400 W
Input Voltage Range: 85–264 V AC
Input Frequency: 47–63 Hz
Operating Temperature Range: -10°C to 60°C (14°F to 140°F)
Efficiency: > 90% at full load
Protection: Overload, overvoltage, and short-circuit protection
About Foxboro P0922YU FPS400-24
WIDE-RANGE INPUT VOLTAGES
A high-efficiency input circuit automatically acceptseither ac or dc input voltages. The 120/240 V ac or125 V dc input circuit (P0922YU) provides a range of85 to 265 V ac at 47 to 63 Hz operation (or 108 to145 V dc) to meet world-wide power requirements.The 24 V dc power supply input circuit (P0922YC)accepts a range of 18 V dc to 35 V dc.
HIGH EFFICIENCY
The sealed power supply has exceptional efficiency(up to 95% for P0922YU and up to 81% forP0922YC) resulting in high reliability and low failurerates. They have a return-on-investment (ROI) of lessthan two years based upon average electrical ratesand load.
POWER FACTOR CORRECTION CIRCUITRY
The advanced design for ac inputs (P0922YU)provides an active sinusoidal current profile for nearunity controlled power factor.
CURRENT LIMITING
The power supply operates as a constant voltagesource with maximum load ratings as listed in thespecifications. If load current attempts to exceedgreater than 110% of maximum current at the rated25°C load, the output voltage begins to decreasetoward zero, thereby limiting the current delivered tothe load. Upon removal of overload, normal operationresumes.
OVERVOLTAGE SHUTDOWN
Automatic shutdown occurs if operating conditionscause excessive output voltage. After the occurrenceof an overvoltage shutdown, input power must beinterrupted to re-establish the output. After the causeof the shutdown has been removed, the shutdowncircuit resets in less than 30 seconds after theremoval of input power.
FAQs
Q: What is the typical use of the Foxboro P0922YU FPS400-24 Power Supply?
A: The FPS400-24 is typically used in industrial automation and process control applications, providing power to distributed control systems (DCS) and other equipment such as PLCs and sensors.
Q: How does the wide input voltage range benefit the Foxboro P0922YU FPS400-24?
A: The wide input voltage range (85-264 V AC) makes the FPS400-24 suitable for use in various global regions with different power standards, offering flexibility in installations.
Q: Can the Foxboro P0922YU FPS400-24 be used in harsh environmental conditions?
A: Yes, the power supply is designed to function in challenging conditions with an operating temperature range from -10°C to 60°C, making it ideal for industrial environments where temperature fluctuations are common.
Q: How does the compact design of the FPS400-24 help in installation?
A: The compact form factor allows the FPS400-24 to be mounted in tight spaces within control panels or cabinets, optimizing available space and making it ideal for installations with limited room.
