CTI-Control Technology Inc 2501 901C-2501 8 In / 4 Out Analog Module

The CTI-Control Technology Inc 2501 901C-2501 Analog Module is a high-density industrial I/O module designed for mixed analog signal processing in PLC-based automation systems. It provides 8 analog input channels and 4 analog output channels, enabling simultaneous data acquisition and process control within a single compact module.The CTI 2501 901C-2501 module is engineered as a direct functional replacement for legacy Siemens 505 series analog modules, making it widely used in retrofit and system upgrade projects. It converts analog field signals from sensors such as temperature transmitters, pressure devices, and flow instruments into digital values for PLC processing, while also generating analog output signals to control actuators and industrial equipment.Based on industrial documentation, the CTI 2501 901C-2501 series is designed for high-speed analog conversion, flexible signal configuration, and seamless compatibility with Siemens 505 systems, making it a widely adopted solution for industrial control integration.

Model: 2501 901C-2501
Product Type: Analog Input / Output Module
Input Channels: 8 analog input channels
Output Channels: 4 analog output channels
Input Signal Range: -10 V to +10 V / 0–20 mA / 4–20 mA selectable
Output Signal Range: 0–10 V / 0–20 mA configurable
Resolution: Up to 16-bit precision class
Sampling/Update Time: ~6 ms per channel (high-speed update)
Isolation: 1500 V channel-to-backplane isolation
Power Consumption: Approx. 3–10 W (system dependent)
Backplane Compatibility: CTI 2500 Series / Siemens 505 I/O base
Communication System: PLC backplane digital integration
Mounting Type: Rack-mounted modular I/O slot
Operating Temperature: Industrial grade (typical -20°C to +60°C range)

1. Industrial automation control systems

2. Process monitoring and control
3. Manufacturing production lines
4. Chemical and petrochemical systems
5. Power plant auxiliary control systems
6. Water treatment and utility monitoring
7. Legacy PLC system upgrades (Siemens 505 replacement systems)

Is CTI 2501 901C-2501  not the part you are wanting?
Check out the rest of our website to see what else we have to offer!

• Hybrid Analog Signal Integration: The 2501 901C-2501 serves as a versatile hybrid module, integrating 8 high-precision analog inputs and 4 analog outputs into a single compact unit.

• Siemens 505 Retrofit Compatibility: By implementing the 2501 901C-2501, facility managers can easily modernize legacy Siemens 505 system architectures.
• Standardized Industrial Design: As a cornerstone of the CTI 2501 901C-2501 Series, this module adheres to strict industrial standards, offering a durable and dependable hardware upgrade path for any facility currently utilizing classic 505-style control platforms.
• High-Speed Real-Time Processing: The 2501 901C-2501 is optimized for high-speed signal conversion with fast update cycles, making it an ideal choice for real-time control applications where rapid response to changing process variables is critical for maintaining production efficiency and safety.
• Advanced Electrical Isolation: Designed to withstand harsh industrial environments, the 2501 901C-2501 features robust electrical isolation that protects the PLC backplane from field-side interference.
