Overview
The MVI69-MNET module is a single-slot solution that provides a powerful connection between Rockwell Automation® CompactLogix processors and Modbus TCP/IP network applications. The Modbus TCP/IP network applications include those networks hosted by Modicon Quantum processors, networks controlled by operator interface software applications, and the growing number of manufactured devices that support this protocol.
Technical specifications
| Manufacturer: | ProSoft |
| Model: | MVI69-MNETC |
| Communication Protocol: | Modbus TCP/IP |
| Compatible PLCs: | Allen-Bradley CompactLogix |
| Ethernet Ports: | 10/100 Mbps, auto-negotiation |
| Client Connections: | Supports multiple simultaneous clients |
| Server Connections: | Allows multiple devices to connect |
| Configuration Interface: | Web-based and Add-On Instructions (AOIs) |
| Data Handling: | Supports up to 256 Modbus TCP/IP commands |
| Operating Temperature: | 0°C to 60°C (32°F to 140°F) |
| Power Requirements: | 5V DC, supplied by the CompactLogix backplane |
Features and Benefits
Support for the storage and transfer of up to 5000 registers to/from the PLC processor using the block transfer interface
User-definable module memory usage
10/100 Base-T Ethernet-compatible interface
All data mapping begins at Modbus register 40001
Configurable parameters for the Client, including a minimum response delay of 0 to 65535 milliseconds
Floating-point support for Enron, Daniels®, and other floating-point data types
Single-Slot, 1769 backplane-compatible
The module is recognized as an Input/Output module and has access to processor memory for data transfer between processor and module.
Ladder Logic is used for data transfer between module and processor. Sample ladder file included.
Configuration data obtained from configuration text file downloaded to module. Sample configuration file included.
Supports all CompactLogix and MicroLogix 1500 LRP Controllers except 1769-QBFC1B, 1769-L16x, and 1769-L18x.
Applications
The MVI69-MNETC module is widely used in industrial automation and process control systems, including:
- Oil & Gas: Communication between CompactLogix controllers and Modbus-enabled flow meters or RTUs.
- Water Treatment Plants: Integrating Modbus TCP/IP sensors and actuators with PLCs.
- Power Plants: Connecting CompactLogix with SCADA systems and remote monitoring equipment.
- Manufacturing: Enabling connectivity between PLCs and industrial robots or smart sensors.
- Building Automation: Controlling HVAC systems and energy management devices via Modbus TCP/IP.
