330103-02-04-10-02-CN
Bently Nevada 330103-02-04-10-02-CN 3300 XL 8 mm Proximity Probe
330103-02-04-10-02-CN is a M10 × 1 unarmored probe with a 20 mm unthreaded length, 40 mm case and 1.0 m standard cable. The decoded values below are kept separate from similar part numbers and are limited to manufacturer documentation.
Confirmed Product Information
| Manufacturer | Bently Nevada, a Baker Hughes business |
| Product family | 3300 XL 8 mm Proximity Probe |
| Thread and armor | M10 × 1 thread, without armor |
| Unthreaded length option 02 | 20 mm |
| Overall case length option 04 | 40 mm |
| Total length option 10 | 1.0 metre (3.3 feet) |
| Connector and cable option 02 | Miniature coaxial ClickLoc connector, standard cable |
| Regional suffix | CN; confirm the applicable order record and approval certificate |
Applications And Installation Checks
Confirmed Compatibility Conditions
Use only as part of a matched 3300 XL 8 mm system. Match the M10 × 1 thread, 20 mm unthreaded length, 40 mm case, 1.0 m probe length, connector type, required extension-cable length and Proximitor total system length.
Approval And Documentation Check
The public Rev. AN ordering table defines approval options 00 and 05, but does not define the CN suffix. Keep the complete CN code and confirm the current region-specific order record and certificate before acceptance.
Lifecycle And Replacement Guidance
The reviewed manufacturer material does not provide an exact discontinuation date or confirm a universal drop-in replacement for 330103-02-04-10-02-CN. Keep the complete ordering code and verify all mechanical, electrical, system-length, approval and installation conditions before substitution.
Frequently Asked Questions
Will 330103-02-04-10-02-CN work with any Bently Nevada Proximitor sensor?
No. Use it with the matched 3300 XL 8 mm transducer system and confirm that the probe plus extension cable equals the Proximitor sensor total system length.
Which dimensions distinguish 330103-02-04-10-02-CN from the similar 80 mm case version?
This code specifies a 20 mm unthreaded length and 40 mm overall case length. The 330103-02-08 configuration uses an 80 mm case and must not be treated as the same mechanical part.
Does 330103-02-04-10-02-CN include armor or a connector protector?
No armor is defined by base number 330103. Connector option 02 specifies the standard ClickLoc connector without a connector protector.
What does the CN suffix on 330103-02-04-10-02-CN mean?
The reviewed public manufacturer ordering table does not define CN. Confirm the exact region-specific order record and certificate; do not replace CN with 00 or 05 without manufacturer confirmation.
Is a direct successor or discontinuation date published for 330103-02-04-10-02-CN?
The reviewed manufacturer datasheet does not state a discontinuation date or name an exact direct successor for this complete ordering code.
Model Identification
Use the complete number 330103-02-04-10-02-CN. Hyphen placement and zero padding are significant in Bently Nevada ordering codes. Similar-looking suffixes identify different dimensions, cable constructions, approvals or fittings, so quotations and replacements must be checked against the full label.
Manufacturer References
Bently Nevada datasheet 141194 Rev. AN, 3300 XL 8 mm Proximity Transducer System.
