BENTLY NEVADA PRODUCT INFORMATION

330702-00-30-10-01-05

Name: Bently Nevada 330702-00-30-10-01-05 3300 XL 11 mm Armored Proximity Probe Manufacturers Suppliers - PLC Leader
Brand: Bently Nevada
SKU: 319666554

Bently Nevada 330702-00-30-10-01-05 3300 XL 11 mm Armored Proximity Probe

330702-00-30-10-01-05 is a 1/2-20 UNF armored 3300 XL 11 mm probe with 0.0 in unthreaded length, a 3.0 in case, 1.0 m total length, connector protector and multiple approvals. Every value below is tied to this complete ordering code and is not copied from a similar suffix.

Confirmed Product Information

Manufacturer	Bently Nevada, a Baker Hughes business
Probe family 330702	3300 XL 11 mm probe, 1/2-20 UNF thread, with armor
Unthreaded length option 00	0.0 in
Overall case length option 30	3.0 in
Total length option 10	1.0 m (3.3 ft)
Connector / cable option 01	Miniature coaxial ClickLoc connector with connector protector, standard cable
Approval option 05	Multiple approvals
System output	3.94 V/mm (100 mV/mil) for non-contacting vibration and displacement measurement
Linear range	4.0 mm (160 mil)
Frequency range	0 to 8 kHz
Probe cable attachment	CableLoc construction, 330 N (75 lb) pull strength
Target calibration	Factory calibrated to AISI 4140 steel unless another target material is specified

Applications

✓

Axial thrust-position measurement requiring the 11 mm family's extended range.

✓

Ramp differential-expansion measurement on steam turbines.

✓

Reciprocating-compressor rod-position or rod-drop measurement, tachometer, zero-speed and Keyphasor applications.

Confirmed Compatibility And Installation Conditions

Use the probe only with matching 3300 XL 11 mm extension cable and Proximitor sensor components for the selected total system length.

When upgrading a 7200-series 11 mm or 14 mm system, replace every transducer component and update the monitoring-system configuration as required.

Confirm the 1/2-20 thread, 3.0 in case, armor, connector protector, system length and target calibration.

Connector protectors improve environmental protection; follow the manufacturer installation instructions and do not assume they make an unapproved connection suitable for every environment.

Verify approval markings and the safe-installation documentation for suffix 05.

Lifecycle And Replacement Guidance

The current manufacturer datasheet lists the 330702 family and does not state a discontinuation date or a universal substitute for this exact configuration.

Frequently Asked Questions

Which extension cable and Proximitor sensor match 330702-00-30-10-01-05?

Use only 3300 XL 11 mm system components so the 1.0 m probe plus extension cable equals the selected 5 m or 9 m system length.

Can 330702-00-30-10-01-05 replace a 7200 11 mm probe by itself?

No. The manufacturer requires replacing the probe, extension cable and Proximitor sensor, and the monitoring configuration may also need updating.

What mechanical details distinguish 330702-00-30-10-01-05?

It has a 1/2-20 UNF thread, stainless-steel armor, 0.0 in unthreaded length and a 3.0 in overall case.

Does 330702-00-30-10-01-05 include a connector protector?

Yes. Connector option 01 specifies the ClickLoc connector with connector protector and standard cable.

Which approvals apply to 330702-00-30-10-01-05?

Suffix 05 specifies the multiple-approvals option; confirm the delivered nameplate and destination-specific approval guide before installation.

Model Identification

Use the complete identifier 330702-00-30-10-01-05. Hyphen placement, zero padding and every suffix field are significant; compare the full nameplate and purchase record before ordering.

Manufacturer References

Bently Nevada 3300 XL 11 mm Proximity Transducer System Datasheet, document 146256 Rev. T.
