330851-02-000-040-10-00-05
Bently Nevada 330851-02-000-040-10-00-05 3300 XL 25 mm Proximity Probe
330851-02-000-040-10-00-05 is a commonly stocked, multiple-approval 3300 XL 25 mm probe with M30 × 2 thread, 40 mm case, 1.0 m FluidLoc cable and no armor. Every value below is tied to this complete ordering code and is not copied from a similar suffix.
Confirmed Product Information
| Manufacturer | Bently Nevada, a Baker Hughes business |
| Product family | 3300 XL 25 mm proximity probe |
| Ordering format | 330851-AA-BBB-CCC-DD-EE-FF |
| Case thread option 02 | M30 × 2 threaded case |
| Unthreaded length option 000 | 0 mm |
| Overall case length option 040 | 40 mm |
| Total probe length option 10 | 1.0 m (3.3 ft) |
| Armor option 00 | No armor |
| Agency approval option 05 | Multiple approvals |
| Stocking status | Listed by the manufacturer as a commonly stocked multiple-approval probe |
| Probe tip / case | PEEK tip; 304 stainless-steel case |
| Integral cable | 75-ohm PFA-insulated FluidLoc cable |
| Probe DC resistance | 6.2 ± 0.5 ohm at 1.0 m |
| Linear range | 12.7 mm (500 mil), approximately 0.63 to 13.33 mm |
| Output over linear range | Approximately -1.5 to -11.5 Vdc |
| Scale factor | 0.787 V/mm (20 mV/mil), nominal |
| Linearity deviation | Less than ±0.31 mm from the best-fit line |
| Frequency response | 0 to 2.7 kHz, +0 / -3 dB, typical |
| Target requirement | Bently Nevada AISI 4140 steel target, minimum 61 mm diameter |
| Probe temperature | -35°C to +200°C; +250°C maximum for less than 24 hours |
| Environmental rating | 100% condensing, non-submersible when connectors are protected |
| Minimum bend radius | 25.4 mm (1.0 in) |
| Recommended / maximum case torque | 68 N·m recommended; 163 N·m maximum |
Matched System Requirements
Differential Expansion Applications
Retrofit And Installation Conditions
Approval Check
Suffix 05 specifies the manufacturer multiple-approvals option. Confirm the certification marking, approval guide and safe-installation drawing for the supplied unit and destination.
Lifecycle And Replacement Guidance
The exact part number appears in the current manufacturer datasheet as a commonly stocked probe. The reviewed source gives no discontinuation date and no universal substitute. Replacement must match case thread, geometry, 1.0 m probe length, full 5 m or 9 m system, target calibration, environmental limits and approvals.
Frequently Asked Questions
Which extension cable and Proximitor Sensor match 330851-02-000-040-10-00-05?
For a 5 m system use the 1.0 m probe with a 4 m extension cable and 5 m Proximitor Sensor; for a 9 m system use an 8 m extension cable and 9 m Proximitor Sensor.
Can 330851-02-000-040-10-00-05 replace a 7200 25 mm or 35 mm probe by itself?
No. The case can physically replace the earlier case and the output is identical, but the probe, extension cable and Proximitor Sensor must all be replaced with matching 3300 XL 25 mm components.
What target and gap conditions apply to 330851-02-000-040-10-00-05?
Use the Bently Nevada AISI 4140 target, at least 61 mm in diameter. Manufacturer performance values are stated at a 7 mm gap under the defined reference conditions.
Is 330851-02-000-040-10-00-05 a current stocked model?
The exact part number is listed in the current manufacturer datasheet as a commonly stocked multiple-approval probe; availability still requires an RFQ check.
What approvals apply to 330851-02-000-040-10-00-05?
Suffix 05 is the multiple-approvals option. Verify the supplied marking and destination-specific safe-installation documents before use.
Model Identification
Use the complete identifier 330851-02-000-040-10-00-05. Each zero-padded field defines this page configuration; similar 330173 or 330851 codes may specify different threads, dimensions, cable lengths, armor, connectors or approvals.
Manufacturer References
Bently Nevada 3300 XL 25 mm Proximity Transducer System Datasheet, document 163236 Rev. M; Bently Nevada Approvals Quick Reference Guide, document 108M1756.
