3300 5 MM PROXIMITY PROBE

330173-00-05-10-02-00

Name: Bently Nevada 330173-00-05-10-02-00 3300 5 mm Proximity Probe Manufacturers Suppliers - PLC Leader
Brand: PLC Leader
SKU: 319008383

Bently Nevada 330173-00-05-10-02-00 3300 5 mm Proximity Probe

330173-00-05-10-02-00 is an M8 × 1 threaded 3300 5 mm probe without armor, configured with a 50 mm case, 1.0 m cable and miniature coaxial ClickLoc connector. Every value below is tied to this complete ordering code and is not copied from a similar suffix.

Confirmed Product Information

Manufacturer	Bently Nevada, a Baker Hughes business
Product family	3300 5 mm proximity probe
Ordering format	330173-AA-BB-CC-DD-EE
Thread and armor	M8 × 1 thread, without armor
Unthreaded length option 00	0 mm
Overall case length option 05	50 mm
Total length option 10	1.0 m (3.3 ft)
Connector and cable option 02	Miniature coaxial ClickLoc connector, standard cable, without connector protector
Agency approval option 00	Standard ordering option 00; no multiple-approval suffix
Probe tip / case	PPS tip; AISI 303 or 304 stainless-steel case
Integral cable	75-ohm triaxial, FEP insulated
Probe DC resistance	7.59 ± 0.50 ohm at 1.0 m
Linear range	2.0 mm (80 mil), approximately 0.25 to 2.3 mm from the target
Recommended electrical gap	1.27 mm (50 mil)
Scale factor	7.87 V/mm (200 mV/mil), ±6.5% typical
Linearity deviation	Less than ±0.038 mm (±1.5 mil), typical
Frequency response	0 to 10 kHz, +0 / -3 dB
Minimum target sizes	15.2 mm flat target; 50.8 mm minimum shaft, 76.2 mm recommended
Probe temperature	-35°C to +177°C (-31°F to +351°F)
Minimum bend radius	25.4 mm (1.0 in)
Recommended / maximum case torque	5.1 N·m recommended; 7.3 N·m maximum

System Configuration And Electrical Data

Use one 3300 5 mm probe with a matched 3300 XL extension cable and 3300 XL Proximitor Sensor; the probe alone is not a complete transducer system.

The Proximitor Sensor accepts one non-contacting 3300 5 mm probe and extension cable. Supply is -17.5 to -26 Vdc at 12 mA maximum; operation above -23.5 Vdc may reduce linear range.

Use 3-conductor shielded triad field wiring, 0.2 to 1.5 mm² (16 to 24 AWG). Maximum sensor-to-monitor wiring length is 305 m (1000 ft).

Factory calibration is for AISI 4140 steel unless another target material is specified and calibrated by the manufacturer.

Applications

Radial vibration and shaft position measurement on fluid-film bearing machines.

Keyphasor and speed measurement where the documented 3300 5 mm system is appropriate.

Space-limited installations where the smaller 5 mm probe body is required; Bently Nevada recommends the 3300 XL 8 mm probe where physical clearance permits because it is more mechanically robust.

Confirmed Installation Conditions

✓

The smaller 5 mm package retains the same 2 mm linear range as the 3300 XL 8 mm family, but it does not reduce side-view clearance or tip-to-tip spacing requirements.

✓

Keep probe tips generally at least 40 mm apart axially or 38 mm apart radially to limit cross-talk to approximately 50 mV; small shaft diameters can also change scale factor.

✓

M8 × 1 thread engagement must not exceed 12 mm. Excess engagement can bind the case and cause damage not covered by the manufacturer warranty.

✓

The probe uses a fluorocarbon O-ring pressure seal but is not pressure-tested before shipment. The installation must contain liquids or gases and consider erosion or leakage in extreme-pH service.

✓

The ClickLoc connector is finger-tight and needs no special tool. This option does not include a connector protector; follow the extension-cable instructions for silicone-tape sealing and do not use that method where the joint is exposed to turbine oil.

Approval Check

Ordering suffix 00 is not the multiple-approvals suffix. Verify the supplied unit marking and the applicable site installation documents before hazardous-area use.

Lifecycle And Replacement Guidance

The reviewed current 2025 manufacturer datasheet lists the 330173 ordering family and does not identify this exact code as discontinued. No universal replacement is stated. Any change must preserve the thread, case geometry, total electrical length, connector, target calibration, environmental sealing and system performance requirements.

Frequently Asked Questions

Which extension cable and Proximitor Sensor must be used with 330173-00-05-10-02-00?

Use a matching 3300 XL extension cable and 3300 XL Proximitor Sensor so the selected total system length and calibration agree with the project documentation.

Can 330173-00-05-10-02-00 directly replace a 3300 XL 8 mm probe?

Do not assume a direct replacement. Although the 5 mm and 8 mm families share a 2 mm linear range, probe geometry, robustness, mounting, cable, Proximitor Sensor and calibration must all be checked.

What clearance and cross-talk checks apply to 330173-00-05-10-02-00?

The 5 mm tip does not reduce side-view or tip-to-tip clearance. The manufacturer generally calls for at least 40 mm axial or 38 mm radial tip separation to limit cross-talk.

How should the connector on 330173-00-05-10-02-00 be protected?

Option 02 has a ClickLoc connector without protector. Apply the manufacturer extension-cable sealing instructions and confirm oil exposure, moisture and site environmental requirements.

Is 330173-00-05-10-02-00 discontinued or assigned a universal replacement?

The current manufacturer datasheet reviewed still lists the 330173 family and states no universal replacement for this exact configuration.

Model Identification

Use the complete identifier 330173-00-05-10-02-00. Each zero-padded field defines this page configuration; similar 330173 or 330851 codes may specify different threads, dimensions, cable lengths, armor, connectors or approvals.

Manufacturer References

Bently Nevada 3300 5 mm Proximity Transducer System Datasheet, document 172036 Rev. T.
