3300 XL 25 MM PROXIMITY PROBE

330851-02-000-080-90-01-05

Name: Bently Nevada 330851-02-000-080-90-01-05 3300 XL 25 mm Proximity Probe Manufacturers Suppliers - PLC Leader
Brand: PLC Leader
SKU: 319000401

Bently Nevada 330851-02-000-080-90-01-05 3300 XL 25 mm Proximity Probe

330851-02-000-080-90-01-05 is a M30x2 threaded 25 mm probe with 80 mm case, 9 m total length, stainless-steel armor and multiple approvals. The confirmed fields below are kept separate from similar part numbers and are limited to reviewed manufacturer documentation.

Confirmed Product Information

Manufacturer	Bently Nevada, a Baker Hughes business
Probe family	3300 XL 25 mm proximity probe
Case type option 02	M30x2 thread
Unthreaded length option 000	0 mm
Overall case length option 080	80 mm
Total length option 90	9.0 metres (29.5 feet)
Armor option 01	AISI 302 stainless-steel armor with PFA outer jacket
Agency approval option 05	Multiple Approvals
System linear range	12.7 mm (500 mil), approximately 0.63 to 13.33 mm from target
Average scale factor	0.787 V/mm (20 mV/mil) nominal
Probe temperature	-35°C to +200°C; +250°C maximum for less than 24 hours
Matched system length	9 metres including any extension cable

Applications And Installation Checks

Differential-expansion measurement on mid-size and large steam turbine generators.

Single-ramp or complementary-input DE arrangements using the matched 25 mm Proximitor sensor and mounting hardware.

Long integral-probe installations requiring an M30x2 case, 80 mm case length and stainless-steel armor.

Confirmed Compatibility Conditions

Use the 9 m probe with a 9 m 3300 XL 25 mm Proximitor sensor; if an extension cable is used, probe plus cable must equal 9 m.

Confirm the M30x2 mounting interface, 0 mm unthreaded length, 80 mm case and armored cable routing.

Use only 3300 XL 25 mm system components and confirm target material, gap, monitor input and differential-expansion geometry.

Observe the published probe-temperature limits and the short-term +250°C exposure limit of less than 24 hours.

Approval Check

Option 05 specifies Multiple Approvals. Confirm the country-specific approval, barrier arrangement and installation drawing for the final destination.

Lifecycle And Replacement Guidance

This exact configuration is included in the current manufacturer ordering table reviewed. No discontinuation date or universal replacement is stated; every mechanical, electrical, armor, length and approval field must match before substitution.

Frequently Asked Questions

What case and mounting dimensions does 330851-02-000-080-90-01-05 use?

It uses an M30x2 threaded case, 0 mm unthreaded length and an 80 mm overall case length.

What total system length applies to 330851-02-000-080-90-01-05?

Option 90 specifies 9.0 metres. The probe and any extension cable must equal the matched 9 m Proximitor sensor system length.

Is 330851-02-000-080-90-01-05 armored?

Yes. Option 01 specifies stainless-steel armor with a PFA outer jacket.

Which measurement is 330851-02-000-080-90-01-05 designed for?

The 3300 XL 25 mm system is designed primarily for steam-turbine differential-expansion measurement.

What temperature limits apply to 330851-02-000-080-90-01-05?

The probe range is -35°C to +200°C, with +250°C allowed only for short exposure of less than 24 hours.

Model Identification

Use the complete identifier 330851-02-000-080-90-01-05. Hyphen placement, zero padding, XX or XXX positions and MOD references are significant. Similar-looking codes can identify different dimensions, cable lengths, fittings, mounting details, approvals or controlled modifications.

Manufacturer References

Bently Nevada 3300 XL 25 mm Proximity Transducer System datasheet 163236 Rev. M.
