330180-X1-05 MOD 145004-75
Bently Nevada 330180-X1-05 MOD 145004-75 3300 XL 8 mm Proximitor Sensor
330180-X1-05 MOD 145004-75 is a modified 330180 Proximitor sensor identified by X1, approval option 05 and MOD 145004-75; the X1 configuration requires the controlled manufacturer record. The confirmed fields below are kept separate from similar part numbers and are limited to reviewed manufacturer documentation.
Confirmed Product Information
| Manufacturer | Bently Nevada, a Baker Hughes business |
| Base part number | 330180, 3300 XL Proximitor sensor |
| Total length / mounting option X1 | Not decoded in the public standard ordering table |
| Agency approval option 05 | CSA, ATEX and IECEx approvals |
| MOD identifier | 145004-75 |
| Sensor input | One non-contacting 3300-series 5 mm or 3300 XL 8 mm probe and extension cable |
| Power | -17.5 to -26 Vdc without barriers, 12 mA maximum; -23 to -26 Vdc with barriers |
| Output resistance | 50 ohm |
| Operating temperature | -52°C to +100°C (-62°F to +212°F) |
| Storage temperature | -52°C to +105°C (-62°F to +221°F) |
| Terminal design | SpringLoc terminal strips |
Applications And Installation Checks
Confirmed Compatibility Conditions
- Keep 330180-X1-05 and MOD 145004-75 together; do not substitute another 330180 MOD or a standard mounting code without confirmation.
- Match probe length plus extension-cable length to the total electrical system length defined by the X1 configuration.
- Confirm probe family, connector, target material, field wiring, monitor input, mounting base, barriers and hazardous-area approval.
- Mixing XL and non-XL 3300-series 5 mm and 8 mm components limits performance to the non-XL system specification.
Lifecycle And Replacement Guidance
The reviewed public datasheet does not provide a discontinuation date or direct replacement for X1 with MOD 145004-75. A substitute must match the controlled MOD record, total system length, mounting, approvals and electrical performance.
Frequently Asked Questions
What does X1 mean in 330180-X1-05 MOD 145004-75?
The current public standard ordering table does not decode X1. Obtain its total-length and mounting definition from the controlled MOD record.
Why must MOD 145004-75 remain with 330180-X1-05 MOD 145004-75?
It identifies the modified manufacturer configuration and prevents confusion with other 330180-X1-05 MOD versions.
Which probes can connect to 330180-X1-05 MOD 145004-75?
The standard 330180 input supports one non-contacting 3300-series 5 mm or 3300 XL 8 mm probe with its matched extension cable; confirm the X1 MOD configuration.
What power supply does 330180-X1-05 MOD 145004-75 require?
The standard sensor specification is -17.5 to -26 Vdc without barriers at 12 mA maximum, or -23 to -26 Vdc with barriers.
Can another 330180-X1-05 MOD replace 330180-X1-05 MOD 145004-75?
Do not assume equivalence. Compare the MOD record, total electrical length, mounting, probe family, field wiring and approvals.
Model Identification
Use the complete identifier 330180-X1-05 MOD 145004-75. Hyphen placement, zero padding, XX or XXX positions and MOD references are significant. Similar-looking codes can identify different dimensions, cable lengths, fittings, mounting details, approvals or controlled modifications.
Manufacturer References
Bently Nevada 3300 XL 8 mm Proximity Transducer System datasheet 141194 Rev. AN. X1 and MOD 145004-75 require the controlled manufacturer configuration record.
