24701-28-05-00-070-04-02
Bently Nevada 24701-28-05-00-070-04-02 Stainless Steel Proximity Probe Housing
24701-28-05-00-070-04-02 is a stainless-steel proximity probe housing with an approved 3300 XL 8 mm probe, 0.5 m cable, no standoff adapter and 7.0 in penetration. The confirmed fields below are kept separate from similar part numbers and are limited to the reviewed manufacturer documentation.
Confirmed Product Information
| Manufacturer | Bently Nevada, a Baker Hughes business |
| Housing family | 24701 stainless-steel proximity probe housing assembly |
| Housing and sleeve material | 303 stainless-steel body with 304 stainless-steel sleeve |
| Probe option 28 | 3300 XL 8 mm probe with approval option |
| Probe cable option 05 | 0.5 metre (20 inches) |
| Standoff option 00 | No standoff adapter |
| Probe penetration option 070 | 7.0 inches (approximately 178 mm) |
| Fittings option 04 | One 3/4-14 NPT plug only |
| Mounting thread option 02 | 3/4-14 NPT |
Applications And Installation Checks
Confirmed Compatibility Conditions
- Match the 3300 XL 8 mm reverse-mount probe, 0.5 m cable, 7.0 in penetration and 3/4-14 NPT machine connection.
- Option 00 means no standoff adapter; option 04 supplies one 3/4-14 NPT plug only.
- Confirm sleeve clearance, probe lead length, target gap and conduit routing against the installed housing.
Lifecycle And Replacement Guidance
The reviewed manufacturer material does not provide an exact discontinuation date or identify a universal drop-in replacement for this complete configuration. Keep the full ordering code and verify every mechanical, electrical, approval and installation condition before substitution.
Frequently Asked Questions
Which probe is included in 24701-28-05-00-070-04-02?
Option 28 specifies a 3300 XL 8 mm probe with the manufacturer approval option.
How long is the probe cable in 24701-28-05-00-070-04-02?
Option 05 specifies a 0.5 m cable, approximately 20 inches.
Does 24701-28-05-00-070-04-02 include a standoff adapter?
No. Standoff option 00 means no standoff adapter.
Which fitting and mounting thread are supplied with 24701-28-05-00-070-04-02?
Fittings option 04 supplies one 3/4-14 NPT plug, while mounting option 02 specifies a 3/4-14 NPT mounting thread.
Can 24701-28-05-00-070-04-02 be treated as a CA24701 explosion-proof housing?
Do not assume that. The complete CA identification and the applicable manufacturer certificate are required before claiming the CA explosion-proof configuration.
Model Identification
Use the complete identifier 24701-28-05-00-070-04-02. Hyphen placement, zero padding, XX positions and MOD references are significant. Similar-looking codes can identify different dimensions, probes, cable lengths, fittings or mounting threads, so quotations and replacements must be checked against the complete nameplate and manufacturer record.
Manufacturer References
Bently Nevada datasheet 141600 Rev. AC, 21000, 24701 and 164818 Proximity Probe Housing Assemblies.
