330190-045-01-05
Bently Nevada 330190-045-01-05 3300 XL 4.5 m Armored ETR Extension Cable
330190-045-01-05 is a 4.5 m armored extended-temperature-range extension cable with CSA, ATEX and IECEx approvals. The confirmed fields below are kept separate from similar part numbers and are limited to the reviewed manufacturer documentation.
Confirmed Product Information
| Manufacturer | Bently Nevada, a Baker Hughes business |
| Product family | 3300 XL Extended Temperature Range extension cable |
| Cable length option 045 | 4.5 metres (14.8 feet) |
| Cable option 01 | Armored cable |
| Agency approval option 05 | CSA, ATEX and IECEx approvals |
| Cable construction | 75 ohm triaxial, perfluoroalkoxy (PFA) insulated |
| Operating and storage range | -52°C to +260°C (-62°F to +500°F) |
Applications And Installation Checks
Confirmed Compatibility Conditions
Approval And Documentation Check
Option 05 is listed for CSA, ATEX and IECEx approvals. The country-specific certificate and installation drawing must still be confirmed for the destination and protection method.
Lifecycle And Replacement Guidance
The reviewed manufacturer material does not provide an exact discontinuation date or identify a universal drop-in replacement for this complete configuration. Keep the full ordering code and verify every mechanical, electrical, approval and installation condition before substitution.
Frequently Asked Questions
What cable length does 330190-045-01-05 provide?
Option 045 specifies 4.5 metres, approximately 14.8 feet.
Is 330190-045-01-05 an armored cable?
Yes. Cable option 01 identifies the armored ETR cable construction.
What temperature range applies to 330190-045-01-05?
The manufacturer lists -52°C to +260°C for operating and storage of the ETR extension cable.
Can 330190-045-01-05 be combined with any probe length?
No. Probe length plus the 4.5 m extension cable must equal the total system length of the matched Proximitor sensor.
Does 330190-045-01-05 use the same performance limits as an all-standard cable system?
Not necessarily. The manufacturer states that any ETR component in the system limits accuracy to the ETR system specification.
Model Identification
Use the complete identifier 330190-045-01-05. Hyphen placement, zero padding, XX positions and MOD references are significant. Similar-looking codes can identify different dimensions, probes, cable lengths, fittings or mounting threads, so quotations and replacements must be checked against the complete nameplate and manufacturer record.
Manufacturer References
Bently Nevada datasheet 141194 Rev. AN, 3300 XL 8 mm Proximity Transducer System.
