24701-28-05-XX-014-04-XX MOD 323933-40-02

Bently Nevada 24701-28-05-XX-014-04-XX MOD 323933-40-02 24701 Stainless Steel Proximity Probe Housing

The reviewed current manufacturer datasheet does not give a discontinuation date or a universal replacement for this modified configuration. A substitute must match the controlled MOD drawing and every confirmed mechanical and approval condition.

Why must the MOD identifier remain with 24701-28-05-XX-014-04-XX MOD 323933-40-02?

MOD 323933-40-02 distinguishes a manufacturer-controlled configuration that the public standard ordering table does not fully decode.

Which fields are publicly confirmed for 24701-28-05-XX-014-04-XX MOD 323933-40-02?

The public datasheet confirms probe option 28, 0.5 m cable option 05, 1.4 in penetration option 014, and fittings option 04.

What do the XX positions in 24701-28-05-XX-014-04-XX MOD 323933-40-02 mean?

The public standard table does not define XX as a standard selectable value. Obtain the values from the OEM drawing, nameplate or original order record.

Can another 24701 housing directly replace 24701-28-05-XX-014-04-XX MOD 323933-40-02?

Do not assume a direct replacement. The unknown standoff and mounting thread, MOD identifier, penetration and fittings must all match.

What sleeve-support check applies to 24701-28-05-XX-014-04-XX MOD 323933-40-02?

The manufacturer requires sleeve support when standoff plus penetration exceeds 12 inches. Because the standoff is XX, calculate the final C+D dimension from the controlled drawing before installation. For penetration between 1.0 and 2.0 inches, the manufacturer notes that counterboring may be necessary to reduce probe side-view or rear-view effects.
