24701-28-05-XX-023-04-XX MOD 323933-30-02
Bently Nevada 24701-28-05-XX-023-04-XX MOD 323933-30-02 24701 Stainless Steel Proximity Probe Housing
24701-28-05-XX-023-04-XX MOD 323933-30-02 is a modified 24701 stainless-steel housing identified by MOD 323933-30-02, with an approved 3300 XL 8 mm probe, 0.5 metre (20 inches) cable and 2.3 inches (approximately 58 mm) penetration. The confirmed fields below are kept separate from similar part numbers and are limited to the reviewed manufacturer documentation.
Confirmed Product Information
| Manufacturer | Bently Nevada, a Baker Hughes business |
| Base housing family | 24701 stainless-steel proximity probe housing assembly |
| Housing and sleeve material | 303 stainless-steel body with 304 stainless-steel sleeve |
| Probe option 28 | 3300 XL 8 mm probe with approval option |
| Probe cable option 05 | 0.5 metre (20 inches) |
| Standoff adapter option XX | Not decoded in the public standard ordering table; confirm the controlled MOD configuration |
| Probe penetration option 023 | 2.3 inches (approximately 58 mm) |
| Fittings option 04 | One 3/4-14 NPT plug only |
| Mounting thread option XX | Not decoded in the public standard ordering table; confirm the controlled MOD configuration |
| MOD identifier | 323933-30-02 |
Applications And Installation Checks
Confirmed Compatibility Conditions
Frequently Asked Questions
Why must the MOD identifier remain with 24701-28-05-XX-023-04-XX MOD 323933-30-02?
The public standard ordering table does not decode the complete modified configuration. MOD 323933-30-02 is therefore required when requesting the OEM record, quotation or dimensional confirmation.
Which ordering fields are publicly confirmed for 24701-28-05-XX-023-04-XX MOD 323933-30-02?
The public datasheet confirms option 28 as an approved 3300 XL 8 mm probe, option 05 as a 0.5 metre (20 inches) cable, penetration 023 as 2.3 inches (approximately 58 mm), and fittings option 04 as one 3/4-14 npt plug only.
What do the XX positions in 24701-28-05-XX-023-04-XX MOD 323933-30-02 mean?
The public standard ordering table does not assign XX as a selectable standard value. Confirm both positions from the controlled MOD drawing, original nameplate or manufacturer order record.
Can 24701-28-05-XX-023-04-XX MOD 323933-30-02 be replaced by another 24701 housing with the same penetration?
Do not assume direct replacement. The unknown standoff and mounting-thread details, MOD identifier, probe approval, cable length and fittings all affect compatibility.
What sleeve-support check applies to 24701-28-05-XX-023-04-XX MOD 323933-30-02?
Final sleeve-support requirements depend on the complete standoff-plus-penetration dimension; the XX standoff value must be confirmed from the controlled configuration record.
Model Identification
Use the complete identifier 24701-28-05-XX-023-04-XX MOD 323933-30-02. Hyphen placement, zero padding, XX positions and MOD references are significant. Similar-looking codes can identify different dimensions, probes, cable lengths, fittings or mounting threads, so quotations and replacements must be checked against the complete nameplate and manufacturer record.
Manufacturer References
Bently Nevada datasheet 141600 Rev. AC, 21000, 24701 and 164818 Proximity Probe Housing Assemblies.
