Bently Nevada 24765-01-01 DC LVDT Assembly

The Bently Nevada 24765-01-01 Case Expansion Transducer Assembly is essential for measuring the thermal growth of turbine cases, an important parameter in Turbine Supervisory Instrumentation (TSI). This device helps track machine case expansion during startup and operation, ensuring the alignment of turbine components and preventing damage. The assembly includes a linear variable differential transformer (LVDT) that offers precise measurements of case expansion, contributing to reliable monitoring of turbine performance.

Manufacturer : Bently Nevada
Product No. : 24765-01-01
Product type : Case Expansion Transducer Assembly (dc)
Made in U.S.A
Linear Range Option : 01 = 25.4 mm (1.00 in)
Spring Option : 01 = With spring return
Electrical Scale Factor : 0.346 V/mm (8.79 V/in).
Linear Range : 25.4 mm (1.00 in).
Operating Temperature : -18 ℃ to +71 ℃ (0 ℉ to +160 ℉).
Storage Temperature : -54 ℃ to +93 ℃ (-65 ℉ to +200 ℉).

●Designed to monitor thermal growth of turbine cases, often referred to as shell expansion.
●Utilizes a dual transducer arrangement to provide detailed position information on machine case feet.
●Dual configuration alarms when one foot is obstructed, protecting against potential machine damage.
●Compatible with 3300 and 3500 monitors for enhanced system integration.
●ldeal for measuring temperature growth differentials between the casing and rotor.
●High-temperature version meets TYPE 4 standards, ensuring durability and reliability.
