330901-05-65-05-11-05
Bently Nevada 330901-05-65-05-11-05 3300 XL NSv FluidLoc Proximity Probe
330901-05-65-05-11-05 is a 3300 XL NSv 1/4-28 UNF probe without armor, configured with a 0.5 in unthreaded length, 6.5 in case, 0.5 m FluidLoc cable, connector protector and Multiple Approvals. Every value below is tied to this complete ordering code and is not copied from a similar suffix.
Confirmed Product Information
| Manufacturer | Bently Nevada, a Baker Hughes business |
| Probe family 330901 | 3300 NSv probe, 1/4-28 UNF-2A thread, without armor |
| Unthreaded length option 05 | 0.5 in |
| Overall case length option 65 | 6.5 in |
| Total length option 05 | 0.5 m (20 in) |
| Connector and cable option 11 | Miniature coaxial ClickLoc connector with connector protector; FluidLoc cable |
| Agency approval option 05 | Multiple Approvals |
| System linear range | 1.5 mm (60 mil) in a matched 3300 XL NSv system |
| Incremental scale factor | 7.87 V/mm (200 mV/mil), +12.5% / -20% including interchangeability error |
| Frequency response | 0 to 10 kHz, +0 / -3 dB typical |
| Probe pressure seal | Viton O-ring; probes are not pressure-tested before shipment |
| System lengths | Match probe plus 330930 extension cable to a 5 m or 7 m 330980 Proximitor sensor system |
Applications
Confirmed Compatibility And Installation Conditions
Lifecycle And Replacement Guidance
The current manufacturer datasheet lists the 330901 ordering family and does not state that 330901-05-65-05-11-05 is discontinued. It does not identify a universal direct replacement for this complete code.
Frequently Asked Questions
Which extension cable matches 330901-05-65-05-11-05?
Use 4.5 m for a 5 m NSv system or 6.5 m for a 7 m NSv system, with the matching 330980 Proximitor sensor and required connector/cable option.
Is 330901-05-65-05-11-05 armored?
No. Family 330901 is the 1/4-28 UNF probe without armor; option 11 specifies FluidLoc cable and connector protection, not stainless-steel armor.
What does option 11 mean on 330901-05-65-05-11-05?
It specifies a miniature coaxial ClickLoc connector with connector protector and FluidLoc cable.
Can 330901-05-65-05-11-05 replace a standard 3300 XL 8 mm probe?
No direct probe-only substitution is confirmed. The NSv system has a different mechanical package and must use compatible NSv extension cable and Proximitor sensor.
Which pressure check applies to 330901-05-65-05-11-05?
The probe uses a Viton O-ring pressure seal but is not pressure-tested before shipment; confirm the installed pressure and process compatibility.
Model Identification
Use the complete identifier 330901-05-65-05-11-05. Hyphen placement, zero padding and every suffix field are significant; compare the full nameplate and purchase record before ordering.
Manufacturer References
Bently Nevada 3300 XL NSv Proximity Transducer System Datasheet, document 147385 Rev. R.
